Product Features
- 2400 W continuous program power capacity
- 100 mm (4 in) copper voice coil
- 35 - 1000 Hz response
- 97 dB sensitivity
- Aluminium demodulating ring allows a very low distortion figure
- Double silicone spider with optimized compliance
- Ventilated voice coil gap for reduced power compression
Product Specifications
- Nominal Diameter460 mm (18.0 in)
- Nominal Impedance8 Ω
- Minimum Impedance6.2 Ω
- Nominal Power Handling11200 W
- Continuous Power Handling22400 W
- Sensitivity397.0 dB
- Frequency Range35 - 1000 Hz
- Voice Coil Diameter100 mm (4.0 in)
- Winding MaterialCopper
- Former MaterialGlass Fibre
- Winding Depth25.0 mm (1.0 in)
- Magnetic Gap Depth12.0 mm (0.5 in)
- Flux Density1.1 T
