EVERYONE LOVES BASS !!
- 700 Watts Continuous
- 1400 Watts Peak
- 129 dB Max SPL @ 1 meter
- Birch plywood construction
- Illuminated LED front logo badge
- Convection cooled Class D amplifier
- Adjustable low pass filter
- 3.0″ voice coil
- Quad layer driver design
- 35 mm pole socket & durable handles
.
3.0
"
Voice coil
129
dB
Max SPL @ 1 meter
700
watts
Continuous power
1400
watts
Peak power
EVERYONE LOVES BASS !
That is exactly why we have created the T-Sub-AX15B – our 700 W Continuous, 1400 W Peak 15” active subwoofer.
The internal Class D amplifier delivers huge output power into the custom quad-layer 15” Wharfedale Pro LF driver to produce extreme subs and low end pressure into any system. Built for big bass, the plywood constructed cabinet is rock solid and is protected in durable Rhino Rock paint.
You’ll not only ‘feel’ the T-Sub-AX15B, but you will also see it! A new illuminated WP logo badge subtly glows and adds to the overall on-stage “power” of the new T-Sub.
T-Sub-AX15B is the perfect companion for a Typhon or a Titan active loudspeaker. It also has 75% more power than the current Titan Sub-A15 MKII.
Hold on to your socks! T-Sub-AX15B is going to blow them off!
PERFECT PAIRING
T-Sub-AX15B has been designed to be the perfect partner for Wharfedale Pro plastic active loudspeakers.
Used with a Tourus, a Titan or our flagship Typhon models, T-Sub-AX15B completes the system – bringing new levels of bass to the setup.
+75% MORE POWER
Here at Wharfedale Pro, we are passionate about our products!
But there comes a time when we have to admit defeat!
Our original Titan Sub A15 MKII cannot stand up to T-Sub-AX15B !!! 🙁
T-Sub-AX15B is +75% more powerful than our classic Titan Sub A15 MKII.
Titan Sub A15 MKII T-Sub-AX15B
Continuous Power 400 watts 700 watts
Peak Power 600 watts 1400 watts
LF Voice coil size 2.5″ 3.0″
PROTECT THE BASS
A protective optional soft cover for T-Sub-AX15B Active Subwoofers.
With easy access to both carry handles and a soft protective padding, the T-Sub-15 soft covers are simple to put on and simple to remove – making setup and breakdown easy.
SPECIFICATIONS
- Model Name T-Sub-AX15B
- System Type Active 15″ Subwoofer
- Frequency Response (+/-3 dB) 45 Hz-200 Hz
- Sensitivity @ 1W / 1 m) 97 dB
- Maximum SPL (peak @ 1 m) 129 dB
- Low Frequency Transducer
- Size (mm / inches) 404 mm / 15”
- Coil Size (mm / inches) Quad layer 3.0″
- Impedance 4Ω
- Amplifier
- Low-Frequency Power Amplifier (Class D) 700 w Continuous / 1400 w Peak
- Crossover Frequency LPF 80-200 Hz (adjustable)
- Controls
- Amplifier Protection Yes
- Power On Protection Power switch on / off mute
- Thermal Protection Amplifier shutdown, auto reset
- Driver Protection Yes
- DC Protection Yes
- Short Protection Yes
- Limiter Indicator Red LED
- Input type Balanced
- Input Connector Female XLR
- Input Impedance 47 KΩ Balanced
- Maximum Input Level 5V
- Input Sensitivity -10 dB
- Line Output Connector Male XLR
- Phase Switch Selection 0° / 180°
- AC Power details
- Power Supply SMPS
- AC Power Options 100V-120V and 200V-240V
- Power Indicator Green(back) / Blue logo(front)
- Enclosure
- Enclosure Material 15 mm Plywood
- Colour Black
- Grille 1.5 mm steel
- Pole Mount (Top) 35 mm
- Dimensions (Unpacked):
- Height 591 mm / 23.27″
- Width 454 mm / 17.9″
- Depth 523.9 mm / 20.63″
- Dimensions (packed):
- Height 689 mm / 27.1″
- Width 544 mm / 21.4″
- Depth 610 mm / 24.0″
- Weight
- Net Weight (kg / lbs) 25.7 kg / 56.5lbs
- Gross Weight (kg / lbs) 29.5 kg / 64.9lbs
