Enjoy incredible 8K video and immersive 3D audio from the AVRX2800H. Fill medium-size rooms with more refined sound from a 7.2 or 5.2.2 set up with Dolby Atmos and DTS:X. And with HEOS® Built-in, wirelessly stream online music and share with HEOS-enabled speakers in other rooms.
-
Powerful Sound
Fill a medium-size room with powerful, more refined sound.
-
Immersive 3D audio
Feel fully enveloped in your music or movie sound.
-
Geared for 8K
Enjoy amazing video quality from the latest 8K technology available.
-
Music streaming throughout your home
With HEOS® Built-in, easily access streaming music and share with HEOS-enabled speakers in other rooms.
High performance discrete 7-channel amplifier
Discrete high-current amplifiers on all channels to deliver up to 95W per channel (at 8 ohms, 20-20kHz, THD 0.08%)—enough power to drive any speaker.
Immersive audio experience
Get immersed in music and movies with Dolby Atmos® and DTS:X® plus Dolby Surround and DTS Neural:X upmixer to optimize legacy content.
Advanced 8K home theater
8K video is supported on three of six HDMI inputs and two outputs. Enjoy easy video compatibility and great picture quality with HLG, HDR, Dolby Vision, HDR10+, and Dynamic HDR passthrough.
HEOS® Built-in technology
Stream music wirelessly to compatible HEOS-enabled components from a variety of streaming services. Add Denon Home speakers to more rooms and control it all with the HEOS app.
Specifications
-
Multichannel Surround
DTS HD Master, DTS:X, DTS:X Pro Yes, Yes, No DTS Neo:X, DTS Neural:X No, Yes DTS Virtual:X Yes Dolby TrueHD, Dolby Atmos, Dolby Atmos Height Virtualization, Dolby Atmos Music Yes, Yes, Yes, Yes Dolby ProLogic Ilz, Dolby Surround No, Yes Multichannel Stereo Yes Max. Number of Processing (Pre-Amp) Channels 7.1 Sound EnhancementsDiscrete Power Amplifier Yes Pure Direct Yes Audyssey MultEQ XT Audyssey Dynamic EQ, Dynamic Volume Yes, Yes Compressed Audio Restorer Yes NetworkMedia Server Yes HEOS Wireless Multi-Room Technology Yes Alexa / Google Voice Assistant / Apple HomePod Yes, Yes, Yes Lossy Formats: MP3, WMA, AAC Yes, Yes, Yes Lossless Formats: FLAC, ALAC, WAV Yes, Yes, Yes Lossless Formats: FLAC HD, WAV, ALAC (all 192kHz/24 bit) Yes, Yes, Yes DSD Audio Streaming Yes (2.8/5.6MHz) AirPlay 2 Yes TuneIn Yes Spotify Connect Yes Pandora Yes SiriusXM* Yes Roon Tested Yes HEOS App Control Yes Compatible with Remote APP for Smart Phones Denon 2016 AVR Remote Ethernet Ports Yes Wi-Fi Yes Bluetooth Yes HDMIHDMI Inputs: Back, Front 6, No HDCP2.3 support Yes HDMI Outputs: Main, Zone 2, No HDMI 2.1: 8K/60Hz AB, 4K/120Hz AB Yes, Yes HDR, HLG, Dolby Vision, HDR10+, Dynamic HDR Yes , Yes, Yes, Yes, Yes ALLM (Auto Low Latency Mode) Pass-through for gaming Yes Variable Refresh Rate, Quick Flame Transport, Quick Media Switching Yes, Yes, No 3D Signal Pass-through Yes 8K Signal Pass-Through, Scaling, GUI Overlay Yes, Yes, Yes Audio Return Channel (ARC), Enhanced ARC Yes, Yes Auto LipSync Yes Multi-room CIMulti-Room Zones 2 Zone Audio Source: HDMI; Optical, Coax, Network, USB; Analog Yes (2ch), Yes (2ch), Yes, Yes Zone Audio Output: Speaker, Pre-Out Yes, Yes IP Control, RS232 Control, Web Control, App Control Yes, Yes /Yes, Yes Remote In / Out Yes, Yes HDMI Diagnostics Yes OthersAuto Speaker Setup by Microphone Audyssey MultEQ XT Front Display 1-Line FLD GUI Languages 3 Setup Assistent Yes Quick Select Plus, Quick Select Yes, No Variable Crossover Yes Optimized Bass Redirection Yes ECO Mode Yes Auto Power Off Yes Sleep Timer Yes Inputs OutputsHDMI In, Out 6, 2 Multi-Room Video Out: Video, HDMI No, No Analog In, Out 4, No Phono (MM) In Yes Digital In: Optical, Coaxial 2, 1 Multi-Room Out: Analog, Digital 1, No Multichannel Preout Yes (0.2) Subwoofer Out 2 Speaker Terminal: Gold-Plated Screw, Regular Screw No, Yes Number of Speaker Terminals 7 Speaker A / B Assignable Bi-amp Drive Assignable Multi-Room Speaker Terminal Assignable Front Inputs: Audio, Composite, Digital (Opt), HDMI, USB No, No, No, No, Yes USB Audio, Made for iPod, Made for iPhone Yes, No, No AM/FM Tuner Yes SpecificationsNumber of Power Amps 7 Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive) 95W Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive) 125W Power Output (6 ohm, 1 kHz, 10% 1ch Drive) 185W GeneralSystem Remote Control RC-1253 Pre-Programmed, Learnable, LCD Display No, No, No Power Consumption in W 500 Power Consumption No-Sound (ECO On / Off) in W 35W/75W Standby Consumption in W 0.1 CEC Standby Consumption in W 0.5 Network Standby Consumption in W Less than 2.0 Maximum Dimensions
Antenna: Horizontal: (W x D x H) in Inches
Antenna: Vertical: (W x D x H) in Inches
W/O Antenna: (W x D x H) in Inches17.1 x 13.4 x 6.6
( 17.1 x 13.4 x 9.3 )
【 17.1 x 13.0 x 6.6 】Weight in LBS 21.0 Weight in LBS (Packaging) 25.4
